HARDWARE FEATURES

Processor
Qualcomm CPU

Interface
2 Gigabit Ethernet Ports (WAN/LAN auto-sensing) per Deco unit

Button
1 Reset button on the underside

External Power Supply
12 V/1.2 A

Dimensions
Φ3.6 in. x 7.5 in. (Φ90.7 mm x 190 mm)

Antenna Type
2 internal dual-band antennas per Deco unit

WIRELESS FEATURES

Wireless Standards
IEEE 802.11 ac/n/a 5 GHz, IEEE 802.11 b/g/n 2.4 GHz

Frequency
2.4 GHz and 5 GHz

Signal Rate
300 Mbps on 2.4 GHz
867 Mbps on 5 GHz

Transmit Power
FCC: <30 dBm
CE: <20 dBm (2.4 GHz)
<23 dBm (5 GHz)

Wireless Security
WPA-PSK/WPA2-PSK

Advanced Functions
● Router/ Access Point Mode
● Optional Ethernet Backhaul
● Guest network
● TP-Link Mesh Technology:
MU-MIMO
Auto Path Selection
Self-Healing
AP Steering
Band Steering
Beamforming

SOFTWARE FEATURES

Quality of Service
WMM

IPv6
Support

WAN Type
Dynamic IP/Static IP/PPPoE/L2TP/PPTP

Management
Local Management, Remote Management

DHCP
Server, Client

Port Forwarding
Support

Access Control
Blacklist

Firewall Security
SPI Firewall

Protocols
Supports IPv4 and IPv6

Advanced Features
Parental Controls
Quality of Service

Advanced Functions
Monthly Reports
Auto FW Update
Expand Wi-Fi by adding more Deco units

Guest Network
2.4 GHz guest network x 1
5 GHz guest network x 1

Beamforming
Support

APP
Easy setup via Deco App

POWER

AC adapter input
100-240V ~ 50/60Hz 0.4A

AC adapter output
12V ⎓ 1.2A
