WIRELESS FEATURES

Wireless Standards
IEEE 802.11n, IEEE 802.11g, IEEE 802.11b

Frequency
2.4-2.4835GHz

Signal Rate
11n: Up to 300Mbps(dynamic)
11g: Up to 54Mbps(dynamic)
11b: Up to 11Mbps(dynamic)

Reception Sensitivity
300M: -71dBm@10% PER
150M: -75dBm@10% PER
54M: -78dBm@10% PER
11M: -93dBm@8% PER
6M: -92dBm@10% PER
1M: -96dBm@8% PER

Wireless Functions
Multiple SSIDs （Up to 8 SSIDs）
Enable/Disable Wireless Radio
Automatic Channel Assignment
Transmit Power Control （Adjust Transmit Power on dBm）
QoS(WMM)
Rate Limit
Reboot Schedule
Wireless Schedule
Wireless Statistics based on SSID/AP/Client

Wireless Security
Captive Portal Authentication
Access Control
Wireless MAC Address Filtering
Wireless Isolation Between Clients
SSID to VLAN Mapping
Rogue AP Detection
802.1X Support
64/128/152-bit WEP / WPA / WPA2-Enterprise,WPA-PSK / WPA2-PSK

Transmission Power
CE:
≤19dBm(EIRP)
FCC:
≤21dBm

HARDWARE FEATURES

Interface
Fast Ethernet (RJ-45) Port *1（Support Passive PoE）

Button
Reset

Power Supply
24V Passive PoE (+4,5pins; -7,8pins. PoE Adapter Included)

Power Consumption
2.8W

Dimensions
7.5×6.8×1.2 in.
(189.4×172.3×29.5mm)

Antenna Type
Internal 2* 4dBi Omni

Mounting
Ceiling /Wall Mounting (Kits included)

Uradna stran proizvajalca: https://www.tp-link.com/us/business-networking/ceiling-mount-access-point/eap110/
